Description
Fully Integrated Barcode Scanning
World-class Honeywell imaging technology covers the broadest range of workflows, from near to extended-range scanning. With the new FlexRange scanner, you can now scan both near and far ranges in a single package, and at lightning-fast speeds.
The Perfect Tablet for Your Environment
Featuring your choice of Windows® or Android™ operating systems, with either Wi-Fi or 4G connectivity, the RT10 is suitable for virtually any enterprise environment.
Fully Rugged
Rugged construction withstands 1.2 m (4 ft) drops to concrete using MIL-STD 810G standards, and has an IP65 rating against dust and water.
Stay Connected
Stay connected with field employees with the RT10 and Honeywell Smart Talk. Connect field workers with subject matter experts using secure PTT, text, voice and video communications.
Integrated Mobile Device Management
Turn data into action with the RT10 and Honeywell Operational Intelligence. Find and fix problems like device abusers, or units that weren’t charged overnight.
Full Range of Accessories
Vehicle docks for forklift mounting, desk docks for office use, hand or shoulder straps for keeping your tablet at your side all day – the RT10 has a full suite of accessories for many different workflows.
Minimized TCO with Mobility Edge
Android models of the RT10 are built on Mobility Edge™, an integrated hardware and software platform that lowers certification, deployment and support costs and ensures application portability across all devices in the Mobility Edge family.
RT10 Android Specifications
MECHANICAL
Dimensions (W x L x H)
271.9 mm x 198.3 mm x 19.5 mm (10.7 in x 7.81 in x 0.77 in)
Weight
1.2 kg (2.65 lbs) with standard battery 1.4 kg (3.1 lbs) with extended battery
ENVIRONMENTAL
Operating Temperature
AC Power: -20°C to 60°C (-4°F to 140°F)
Battery Power: -10°C to 50°C (14°F to 122°F)
Storage Temperature
-30°C to 70°C (-22°F to 158°F)
Humidity
10% to 90% RH, non-condensing
Transit Drop
1.2m (4 ft), MIL-STD-810G, Method 516.6, Procedure IV
Crash Shock
MIL-STD-810G, Method 516.6, Procedure V
Vibration
MIL-STD-810G, Method 514.6, Procedure I
Environmental Sealing
IP65
SECURITY
WLAN Security
OPEN, WEP, WPA/WPA2 (Personal and Enterprise)
Kensington Lock slot
SYSTEM ARCHITECTURE
Processor
2.2 GHz Qualcomm® 64-bit Snapdragon™ octa-core
Operating System
Android P, upgradable through Android R
Memory
4 GB RAM, 32 GB Storage
Display
10.1-inch, 800 NIT brightness,
1920 x 1200 resolution
Optically bonded
Audio
Integrated microphones with noise cancellation
Dual 1W speakers
I/O Ports
1x USB 3.0 (Type A)
1x USB 3.0 (Type C)
1x 3.5mm Audio Combo Connector (Mic in or line out)
1x DC jack
1x Micro SDXC slot
User-accessible microSD: Card up to 512 GB (SDXC/SDHC/ SDIOcompliant)
Keys
1x Power
1x Home
2x Programmable function keys
Volume control
Camera
Rear: 13 MP autofocus with flash
Front: 8 MP
Sensors
Ambient light sensor, accelerometer, gyroscope
Battery
Standard: 5,900 mAh
Extended: 10,280 mAh
Hot-swap battery capability
Scanning Capabilities
Honeywell N6703 Standard Range 1D/2D Imager
Honeywell FlexRange 1D/2D Imager
WIRELESS CONNECTIVITY
WLAN
IEEE 802.11 a/b/g/n/ac; Wi-Fi certified 2×2 MIMO support
Additional WLAN Features
802.11 d/e/h/i/k/r/w
WLAN Security
OPEN, WEP,WPA/WPA2 (Personal and Enterprise)
WWAN
WWAN: WWAN Radio (ATT/VZW/ NA/EU) LTE Advanced Support
Up to 400 Mbps CAT13 LTE downlink
Up to 75 Mbps CAT5 LTE uplink LTE (FDD) – ands 1, 2, 3, 4, 5, 7, 8, 12,13,17, 19, 20, 25, 26, 28, 29 LTE (TDD) – Bands 38, 39, 40, 41
UMTS/HSPA+ (3G) – Bands 1, 2, 4, 5, 6, 8, 9, 19
GSM/GPRS/EDGE Quad-Band (850/900/1800/1900 MHz) 1xRTT/EV-DO – Bands BC0, BC1, BC10 (B26BW)
Bluetooth®
V5.0 Bluetooth and BLE Supported Bluetooth Profiles: HFP, PBAP, A2DP, AVRCP,OPP, SPP, GATT
NFC
Integrated Near Field Communication
Push to Talk (PTT): Supported
GPS Supported Protocols: Simultaneous GNSS. Receiver Support for GPS, GLONASS, Galileo, and Beidou
WARRANTY
3-year limited factory warranty
